MEDISOL AM Medium type bend with antimicrobial technology

  • IMPACT RESISTANCE:2J
  • RESISTANCE TO COMPRESSION:750 Nt

MEDISOL AM bend is a part of MEDISOL AMMEDIFLEX AM conduit system with antimicrobial technology for cable management and protection. It has the same properties as MEDISOL AM conduit and is produced by a fully automated production line. Its antimicrobial technology resists the growth of bacteria by up to 99% within 24 hours

LEARN MORE ABOUT THE INNOVATION

APPLICATION FIELD

Ideal for sanitary areas (hospitals, medical centers & laboratories) and public spaces (schools, nursery homes/rooms & sport centers) and areas requiring implementation of HACCP & ISO 22000 systems such as food industries/warehouses, restaurants, etc.

  • APPLICATION STANDARD:EN 61386.21, ISO 22196
  • INSTRUCTIONS FOR COMPLIANCE:2014/35/EE (LVD), 2011/65/EE (RoHS), 98/8/ΕΕ (BPD)
  • COLOR:RAL 9003 White
  • NOMINAL DIAMETER:Nominal outer diameter (DN/OD)
  • TIGHTNESS DEGREES:min IP 65
  • Product Conformity to all requirements of relative European Directives.
  • Minimum resistance to compression
  • Minimum resistance to impact
  • Min-max permanent application temperature
  • Ingrees protection against solid objects and water (EN 60529)
  • Product with extra UV stability
  • Non flame propagating product
  • Product with up to 99,9% antimicrobial protection
  • Product is not an attractive food to rodents
  • Nominal outer diameter (mm)
  • PROPERTIES
  • CHARACTERISTICS
  • PACKAGING
  • DOWNLOADS
1Resist the growth of bacteria by up to 99% within 24 hours
2Antimicrobial efficacy is tested according to the International Standard ISO 22196
3Engraved with laser printing and packed in 100% recyclable packaging for their maximum protection.
4Medium type impact (2J) resistance at low temperature of -25oC
5High ingress protection (min IP65), when connected with MEDISOL AM coupler
6Not attractive to rodents
7Resistance to UV radiation
Properties
Resistance to impact 2J (at -25oC)
Lower temperature range -25oC
Upper temperature range +60oC
Electrical characteristics With electrical insulated characteristics
Protection against ingress of solid objects min IP65
Protection against ingress of water min IP65
Resistance to flame propagating Non flame propagating



Additional properties
Raw material Heavy metals free (RoHS), specially stabilized thermoplastic U-PVC
Ageing resistance UV stabilized
Antimicrobial technology Resist the growth of bacteria by up to 99% within 24 hours
Rodent repellent Not attractive to rodents



Type Part number
Ø16 4344116 16.0 13.0 27.0 59.0 10 480
Ø20 4344120 20.0 16.8 35.0 74.0 10 480
Ø25 4344125 25.0 21.5 36.7 108.0 10 240
Ø32 4344132 32.0 28.3 47.6 142.0 6 48
Ø40 4344140 40.0 36.0 52.9 144.0 6 84
Ø50 4344150 50.0 45.0 62.0 175.0 4 40
Ø63 4344163 63.0 57.8 77.0 203.0 4 24
