MEDISOL AM Connection coupler of conduits with antimicrobial technology

MEDISOL AM coupler is safely connected with KOUVIDIS rigid and pliable conduits with antimicrobial technology, ensuring minimum Ingress Protection IP65. It’s a part of MEDISOL AM – MEDIFLEX AM and MEDISOL AM HF – MEDIFLEX AM HF conduit systems for cable management and protection. Its antimicrobial technology resists the growth of bacteria by up to 99% within 24 hours.

LEARN MORE ABOUT THE INNOVATION

APPLICATION FIELD

Ideal for exposed electrical installations in sanitary areas and areas requiring implementation of HACCP & ISO 22000 systems.

  • APPLICATION STANDARD:EN 61386.01, ISO 22196, EN 50642
  • INSTRUCTIONS FOR COMPLIANCE:2014/35/EE (LVD), 2011/65/EE (RoHS)
  • COLOR:RAL 9003 White
  • TIGHTNESS DEGREES:min IP 65
  • Product Conformity to all requirements of relative European Directives.
  • Min-max permanent application temperature
  • Ingrees protection against solid objects and water (EN 60529)
  • Product with extra UV stability
  • Non flame propagating product
  • Πιστοποίηση αντιµικροβιακής τεχνολογίας (ISO 22196) από το κορυφαίο Βρετανικό εργαστήριο BIOCOTE
  • Product with up to 99,9% antimicrobial protection
  • Product is made of halogen free raw materials
  • PROPERTIES
  • CHARACTERISTICS
  • PACKAGING
  • DOWNLOADS
1Resist the growth of bacteria by up to 99% within 24 hours
2Antimicrobial efficacy is tested according to the International Standard ISO 22196 and is controlled by the British laboratory BIOCOTE
3High ingress protection (min IP65), when connecting with KOUVIDIS conduits with antimicrobial technology
4It carries an inner lip for the proper conduits fixing and assembling
5No toxic or corrosive gases in case of fire
Properties
Raw material Halogen free, heavy metals free (RoHS) and specially stabilized thermoplastic PO blend
Temperature range -25oC to+120oC
Ingress protection min IP65
Electrical characteristics With electrical insulated characteristics
Ageing resistance UV stabilized
Resistance to flame propagating Non flame propagating
Antimicrobial technology Resist the growth of bacteria by up to 99%
within 24 hours
Halogen free No toxic or corrosive gases in case of fire
Type Part number
Ø16 4244016 20 16 51 1.5 30 2280
Ø20 4244020 23.5 20 52.5 1.5 30 1890
Ø25 4244025 28.5 25 51.5 1.5 30 1440
Ø32 4244032 37 32 65 2 20 560
Ø40 4244040 44.5 40 85 2 15 420
Ø50 4244050 55.6 50 105 2.5 10 200
Ø63 4244063 69.8 63 126 2.8 8 64
