MEDIFLEX PLUS ISR 2layers pliable conduit with anti - electromagnetic technology
- CLASS:33332
- IMPACT RESISTANCE:2J
- RESISTANCE TO COMPRESSION:750 Nt
MEDIFLEX PLUS new 2-layer conduit with anti – electromagnetic technology drives to a new era in indoor surface installations as well as in concealed type in concrete. The corrugated external wall of the conduit provides the necessary flexibility and the required mechanical strength with the use of less raw materials. The internal layer follows the geometry of the outer layer, facilitating the smooth insertion of the cables.
The inner layer of MEDIFLEX PLUS plastic conduit incorporates a new innovative anti – electromagnetic technology which absorbs a part of the electromagnetic radiation emitted by the cables. Moreover, a special ultra-slip material is added in the internal layer which ensures the smooth insertion of the cables.
LEARN MORE ABOUT THE INNOVATION
The conduit is produced by specially stabilized thermoplastic PO blend, halogen free (EN 50642), free of heavy metals (RoHS) and low smoke (EN 61034-2). Therefore, it is the most reliable and safe solution in case of fire, which also meets the requirements of Fire Protection Regulation 364/2016/ΕΕ.
MEDIFLEX PLUS is distributed in the market with a new way of packaging which can save up to 50% more storage and transport space. In addition, this results in a better environmental footprint due to the reduced volume of waste it leaves after use.
APPLICATION FIELD
Ideal for indoor surface installations and concealed type installations in concrete, in places which require extra safety measures such as public gathering places (hotels, shopping malls, airports etc.), places with costly mechanical equipment (engine rooms, industrial spaces, computer rooms etc.), and places with extreme temperature requirements (boiler rooms, freeze chambers etc.).
- APPLICATION STANDARD:EN 61386.22, ΕΝ 50642, ΕΝ 60754-2, ΕΝ 61034-2
- INSTRUCTIONS FOR COMPLIANCE:2014/35/EE (LVD), 2011/65/EE (RoHS)
- COLOR:RAL 7035 light grey (outer layer), RAL 9004 black (inner layer)
- NOMINAL DIAMETER:Βάση εξωτερικής διαμέτρου (DN/OD)
- TIGHTNESS DEGREES:min IP 65
Πιστότητα προϊόντος, ως προς το σύνολο των απαιτήσεων των ευρωπαϊκών oδηγιών στις οποίες ανήκει- Ελάχιστη αντοχή στη συµπίεση
- Ελάχιστη αντοχή στην κρούση
- Βαθµός στεγανότητας έναντι στερεών σωµατιδίων και νερού (EN 60529)
- Αντίσταση στη γήρανση
- Αντίσταση στη διάδοση φλογών
- Μείωση των τριβών λόγω ολισθηρής εσωτερικής επιφάνειας του σωλήνα
- Χαµηλή εκποµπή καπνού κατά την καύση (EN 61034-2)
- Προϊόν από πρώτες ύλες ελεύθερες αλογόνων. ∆εν περιέχει φθόριο, ιώδιο, βρώµιο, χλώριο κ.λ.π. (EN 50642)
- Το προϊόν δεν αποτελεί ελκυστική τροφή για τρωκτικά
- Eξωτερική διάµετρος (mm)
- Εύρος θερµοκρασιακής αντοχής
- Αντιστατική Τεχνολογία
- Αντι-ηλεκτρομαγνητική τεχνολογία
- Αντιχαρακτική τεχνολογία
- PROPERTIES
- CHARACTERISTICS
- PACKAGING
- RECOMMENDED APPLICATIONS
- DOWNLOADS
1The inner layer incorporates an innovative Anti - Electromagnetic Technology
240% lower friction due to special slip material added in the internal layer (test conducted according to IEC/TR 62470)
3No toxic or corrosive gases in case of fire
4High mechanical resistance in high temperature of (105oC)
5Not attractive to rodents (European Patent EP2698792)
6Ideal for indoor surface installations and concealed type installations in concrete
7New specially designed packaging that saves 25% - 50% more storage space
8Lower costs due to its reduced storage space and lower installation time
9Ease of use due to its ability to regain its initial shape after bending.
10Incorporates antistatic technology which protects against static electricity (Patent Protected: 1009810)
11Protection against scratching from cable routing (Patent Protected: 1010513)
12Better visibility of escape ways
| Properties | Class | |
| Resistance to compression | 750Nt/5cm | 3 |
| Resistance to impact | 2J (at-15oC) | 3 |
| Lower temperature range | -15oC | 3 |
| Upper temperature range | +105oC | 3 |
| Resistance to bending | Pliable | 2 |
| Electrical characteristics | With electrical insulated characteristics | 2 |
| Protection against ingress of solid objects | min IP65 | 6 |
| Protection against ingress of water | min IP65 | 5 |
| Resistance against corrosion | Not applicable | 0 |
| Tensile strength | None declared | 0 |
| Resistance to flame propagating | Non flame propagating | 1 |
| Suspended load capacity | None declared | 0 |
| Fire effects | None declared | 0 |
| Environmental impact | Halogen Free | 1 |
| Additional properties | ||
| Raw material | Halogen free, heavy metals free (RoHS) and specially stabilized thermoplastic PO blend | |
| Anti – electromagnetic technology | Absorbs a part of the electromagnetic radiation emitted by the cables | |
| Lower frictions | Special slip material added in the internal layer | |
| Halogen free | No toxic or corrosive gases in case of fire | |
| Low smoke | Better visibility of escape ways | |
| Rodent repellent | Not attractive to rodents | |
| Antistatic Technology | Protection against static electricity | |
| Antiscratch Technology | Protection against scratching from cable routing | |
| Type | Part number |  |
 |
 |
 |
 |
| Ø16 | 2052016 | 16 | 10.5 | 100 | 5,85 | 5850 |
| Ø20 | 2052020 | 20 | 13.7 | 100 | 8.10 | 5600 |
| Ø25 | 2052025 | 25 | 18.1 | 50 | 5.60 | 2600 |
| Ø32 | 2052032 | 32 | 24.2 | 25 | 3.73 | 1100 |
LEGEND
- Recommended
- Not recommended
- Ideal according to the manufacturer
| SCOPES | |
| Exposed | |
| Concealed (underplaster) | |
| Concealed (dry wall) | |
| Concrete | |
| Underfloor in screed | |
| Outdoor | |
| Buried Wood (underground) | |
| Wood | |
| Concealed floor / ceiling | |
